Home > Products > Stepper Motor > DC Motor Brushless DC Motor Brushless Motor Electric Motor Brushed Motor PMDC Motor BLDC Motor NEMA34 1.8° 86HS2a126-508 Stepping Motor Stepper Motor
DC Motor Brushless DC Motor Brushless Motor Electric Motor Brushed Motor PMDC Motor BLDC Motor NEMA34 1.8° 86HS2a126-508 Stepping Motor Stepper Motor
Product DescriptionModel:86hs2A126-508Holding Torque:640N.cmCurrent:5AResistance:0.85ΩMotor Length:126MMWeight:3.8kgMotor are available with different winding and mechanical modification to meet specific applications.ModelHolding Torque (N·cm±10%)Current/Phase(A)Resis......
Send Inquiry
Product Description
Product Description
Model:86hs2A126-508
Holding Torque:640N.cm
Current:5A
Resistance:0.85Ω
Motor Length:126MM
Weight:3.8kg
Motor are available with different winding and mechanical modification to meet specific applications.
Model:86hs2A126-508
Holding Torque:640N.cm
Current:5A
Resistance:0.85Ω
Motor Length:126MM
Weight:3.8kg
Motor are available with different winding and mechanical modification to meet specific applications.
| Model | Holding Torque (N·cm±10%) | Current/Phase(A) | Resistance/Phase (ohms±10%) | Inductance/Phase (mH±20%) | Detent Torque (N·cm) | Rotor Inertia (Kg-cm 2 ) | Length (mm) | Weight (kg) |
| 86HS2A126-408 | 640 | 4.0 | 1.3 | 5.8 | 18.5 | 2.2 | 126 | 3.8 |
| 86HS2A126-508 | 640 | 5.0 | 0.85 | 3.4 | 18.5 | 2.2 | 126 | 3.8 |
| 86HS2A126-278 | 640 | 2.7 | 2.5 | 12.5 | 18.5 | 2.2 | 126 | 3.8 |
