35hm NEMA14 9n. Cm 0.8A 0.9 Degree Step Motor
2 Phase Hybrid Stepping Motor 0.9Degree NEMA14Model: 35HM2A28-084Holding torque: 9N. Cm,Current: 0.8AResistance: 4.5ohms,Inductance: 4.2mH,Length: 28mm,Wire: 4Weight: 130gRemark:Motor are available with diffent winding and mechancial modification to meet specific applications. Model Holding torq......
Send Inquiry
Product Description
2 Phase Hybrid Stepping Motor 0.9Degree
NEMA14
Model: 35HM2A28-084
Holding torque: 9N. Cm,
Current: 0.8A
Resistance: 4.5ohms,
Inductance: 4.2mH,
Length: 28mm,
Wire: 4
Weight: 130g
Remark:
Motor are available with diffent winding and mechancial modification to meet specific applications.
NEMA14
Model: 35HM2A28-084
Holding torque: 9N. Cm,
Current: 0.8A
Resistance: 4.5ohms,
Inductance: 4.2mH,
Length: 28mm,
Wire: 4
Weight: 130g
Remark:
Motor are available with diffent winding and mechancial modification to meet specific applications.
| Model | Holding torque (N.cm±10% | Current/ Phase (A) | Resistance/ Phase (ohms±10%) | Inductance/ Phase (mH±20%) | Detent Torque (N.cm) | Rotor Inertia (g-cm 2) | Lenght (mm) | Weight (Kg) |
| 35HM2A28-084 | 9 | 0.8 | 4.5 | 4.2 | 0.3 | 12 | 28 | 1.3 |
| Model | Holding Torque (N· cm± 10%) | Current/Phase(A) | Resistance/Phase (ohms± 10%) | Inductance/Phase (mH± 20%) | Detent Torque (N· cm) | Rotor Inertia (g-cm 2 ) | Length (mm) | Weight (g) |
| 35HM2A28-084 | 9 | 0.8 | 4.5 | 4.2 | 0.3 | 12 | 28 | 130 |
| 35HM2A28-064 | 9 | 0.55 | 10 | 9.5 | 0.3 | 12 | 28 | 130 |
| 35HM2A28-044 | 9 | 0.36 | 22 | 20 | 0.3 | 12 | 28 | 130 |
| 35HM2A28-046 | 8 | 0.4 | 30 | 12 | 0.3 | 12 | 28 | 130 |
| 35HM2A34-084 | 14 | 0.8 | 6 | 10 | 0.6 | 18 | 34 | 190 |
| 35HM2A34-064 | 14 | 0.55 | 12 | 19 | 0.6 | 18 | 34 | 190 |
| 35HM2A34-044 | 14 | 0.36 | 28 | 42 | 0.6 | 18 | 34 | 190 |
| 35HM2A34-046 | 10 | 0.4 | 30 | 18 | 0.6 | 18 | 34 | 190 |
