1.8° 28HS2a50- 064 10n. Cm 0.6A 2-Phase Stepper Motor
Model: 28HS2A50-064Holding torque: 10N.cmCurrent: 0.6AResistance: 9ohms,Length: 50mmWeigth: 180gWire: 4Remark:Motor are available with different winding and mechanical modification to meet specific applications.ModelHolding Torque (N·cm±10%)Current/Phase(A)Resistance/Phase (ohm......
Send Inquiry
Product Description
Model: 28HS2A50-064
Holding torque: 10N.cm
Current: 0.6A
Resistance: 9ohms,
Length: 50mm
Weigth: 180g
Wire: 4
Remark:
Motor are available with different winding and mechanical modification to meet specific applications.
Holding torque: 10N.cm
Current: 0.6A
Resistance: 9ohms,
Length: 50mm
Weigth: 180g
Wire: 4
Remark:
Motor are available with different winding and mechanical modification to meet specific applications.
| Model | Holding Torque (N·cm±10%) | Current/Phase(A) | Resistance/Phase (ohms±10%) | Inductance/Phase (mH±20%) | Detent Torque (N·cm) | Rotor Inertia (g-cm 2 ) | Length (mm) | Weight (g) |
| 28HS2A28-064 | 4.5 | 0.6 | 4.2 | 2.2 | 0.3 | 6 | 28 | 105 |
| 28HS2A28-044 | 4.5 | 0.35 | 12 | 5.8 | 0.3 | 6 | 28 | 105 |
| 28HS2A33-064 | 6.0 | 0.6 | 5.5 | 3.2 | 0.4 | 8 | 33 | 110 |
| 28HS2A33-044 | 6.0 | 0.35 | 15 | 9.2 | 0.4 | 8 | 33 | 110 |
| 28HS2A41-064 | 6.0 | 0.6 | 7.0 | 6.0 | 0.5 | 11 | 41 | 140 |
| 28HS2A41-044 | 6.0 | 0.35 | 20 | 15 | 0.5 | 11 | 41 | 140 |
| 28HS2A50-064 | 10 | 0.6 | 9.0 | 7.2 | 0.8 | 13 | 50 | 180 |
| 28HS2A50-044 | 10 | 0.35 | 24 | 18.5 | 0.8 | 13 | 50 | 180 |
