China Variable Speed Three Phase Motor with Cast Iron Housing (225M-12P/6P-12/20KW)

Product Description

Product Description
MD (YD)series 3 phase multispeed induction motorderives from Y2 series motor, and it switches poles and output power by transforming the joint mode of winding to matching to the load performance of mechanical equipment. It complies with IEC standard on noise, start torque, vibration value and mounting and overall dimensions. The motors are characteristic in small size, light, stable, firm structure ,good appearance and so on .

Variable Speed Three Phase Motor with Cast Iron Housing (225M-12P/6P-12/20KW)

Technical Data

Type		Power	Current	Speed	η	Power Factor	TST/TN	IST/IN
Type		KW	A	RPM	%	CosΦ	TST/TN	IST/IN
MD80K	4	0.45	1.4	1420	66	0.74	1.5	6.5	1.8
MD80K	2	0.55	1.5	2860	65	0.85	1.6	7	1.8
MD80G	4	0.55	1.7	1420	68	0.74	1.5	6.5	1.8
MD80G	2	0.75	2	2860	66	0.85	1.6	7	1.8
MD90S	4	0.85	2.3	1430	74	0.77	1.5	6.5	1.8
MD90S	2	1.1	2.8	2850	72	0.84	1.6	7	1.8
MD90L	4	1.3	3.3	1430	76	0.78	1.5	6.5	1.8
MD90L	2	1.8	4.3	2850	74	0.84	1.6	7	1.8
MD100LA	4	2	4.8	1430	78	0.81	1.5	6.5	1.8
MD100LA	2	2.4	5.6	2850	76	0.86	1.6	7	1.8
MD100LB	4	2.4	5.6	1430	79	0.83	1.5	6.5	1.8
MD100LB	2	3	5.7	2850	77	0.89	1.6	7	1.8
MD112L	4	3.3	7.4	1450	81	0.83	1.5	6.5	1.8
MD112L	2	4	8.6	2860	80	0.88	1.6	7	1.8
MD132S	4	4.5	9.8	1450	83	0.84	1.5	6.5	1.8
MD132S	2	5.5	11.9	2860	79	0.88	1.6	7	1.8
MD132M	4	6.5	13.8	1450	84	0.85	1.5	6.5	1.8
MD132M	2	8	17.1	2880	80	0.89	1.6	7	1.8
MD160M	4	9	18.5	1460	87	0.85	1.5	6.5	1.8
MD160M	2	11	22.9	2920	82	0.89	1.6	7	1.8
MD160L	4	11	22.3	1460	87	0.86	1.5	6.5	1.8
MD160L	2	14	28.8	2920	82	0.9	1.6	7	1.8
MD90S	6	0.65	2.2	920	64	0.7	1.4	6.5	1.8
MD90S	4	0.85	2.3	1420	70	0.79	1.3	7	1.8
MD90L	6	0.85	2.8	930	66	0.7	1.4	6.5	1.8
MD90L	4	1.1	3	1420	71	0.79	1.3	7	1.8
MD100LA	6	1.3	3.8	940	74	0.7	1.4	6	1.8
MD100LA	4	1.8	4.4	1440	77	0.8	1.3	6.5	1.8
MD100LB	6	1.5	4.3	940	75	0.7	1.4	6	1.8
MD100LB	4	2.2	5.4	1440	77	0.8	1.3	6.5	1.8
MD112M	6	2.2	5.7	960	77	0.75	1.4	6	1.8
MD112M	4	2.8	6.7	1440	77	0.82	1.3	6.5	1.8
MD132S	6	3	7.7	960	79	0.75	1.4	6	1.8
MD132S	4	4	9.5	1440	80	0.82	1.3	6.5	1.8
MD132M	6	4	9.8	960	81	0.76	1.4	6	1.8
MD132M	4	5.5	12.3	1440	80	0.85	1.3	6.5	1.8
MD160M	6	6.5	15.1	970	84	0.78	1.4	6	1.8
MD160M	4	8	17.4	1460	83	0.85	1.3	6.5	1.8
MD160L	6	9	20.6	970	85	0.78	1.4	6	1.8
MD160L	4	11	23.4	1460	84	0.85	1.3	6.5	1.8
MD90L	8	0.45	1.9	680	58	0.63	1.5	5.5	1.8
MD90L	4	0.75	1.92	1420	72	0.87	1.5	6.5	1.8
MD100L	8	0.85	3.1	700	68	0.63	1.5	5.5	1.8
MD100L	4	1.5	3.5	1420	75	0.88	1.5	6.5	1.8
MD112M	8	1.5	5	700	72	0.63	1.5	5.5	1.8
MD112M	4	2.4	5.3	1420	78	0.88	1.5	6.5	1.8
MD132S	8	2.2	7	720	75	0.64	1.5	5.5	1.8
MD132S	4	3.3	7.1	1450	80	0.88	1.5	6.5	1.8
MD132M	8	3	9	720	78	0.65	1.5	5.5	1.8
MD132M	4	4.5	9.4	1440	82	0.88	1.5	6.5	1.8
MD160M	8	5	13.9	730	83	0.66	1.5	5.5	1.8
MD160M	4	7.5	15.2	1450	84	0.89	1.5	6.5	1.8
MD160	8	7	19	730	85	0.66	1.5	5.5	1.8
MD160	4	11	21.8	1450	86	0.89	1.5	6.5	1.8
MD90S	8	0.35	1.6	680	56	0.6	1.5	5	1.8
MD90S	6	0.45	1.4	930	70	0.72	1.5	6	1.8
MD90L	8	0.45	1.9	680	59	0.6	1.5	5	1.8
MD90L	6	0.65	1.9	930	71	0.73	1.5	6	1.8
MD100L	8	0.72	2.9	710	65	0.6	1.5	5	1.8
MD100L	6	1.1	3.1	950	75	0.73	1.5	6	1.8
MD112M	8	1.3	4.5	710	72	0.61	1.5	5	1.8
MD112M	6	1.8	4.8	950	78	0.73	1.5	6	1.8
MD132S	8	1.8	5.8	730	72	0.62	1.5	5	1.8
MD132S	6	2.4	6.2	970	80	0.73	1.5	6	1.8
MD132M	8	2.6	8.2	730	78	0.62	1.5	5	1.8
MD132M	6	3.7	9.4	970	82	0.73	1.5	6	1.8
MD160M	8	4.5	13.3	730	83	0.62	1.5	5	1.8
MD160M	6	6	14.7	980	85	0.73	1.5	6	1.8
MD160L	8	6	17.5	730	84	0.62	1.5	5	1.8
MD160L	6	8	19.4	980	86	0.73	1.5	6	1.8

MD160M	12	2.6	11.6	480	75	0.46	1.2	4	18
MD160M	6	5	11.9	970	84	0.78	1.3	6	1.8
MD160L	12	3.7	16.4	480	77	0.46	1.2	4	1.8
MD160L	6	7	15.8	970	85	0.79	1.3	6	1.8

Package

Frame NO. 80--132 :Package by carton box and then packed by wooden box

Frame NO.160 and above:one wooden box per set
