Ry7030m22 Thickness 10mm-50mm 120V AC Gear Motor with High Torque Low Speed for Blender Juicer
Series motorRY70 seriesMain features:1. The rated voltage / frequency is shown in the table below;2. Shaft characteristics: diameter 5.6.6.35. 8 9 shaft extension part thread, helical gear shaft or worm;3. Stator stack thickness 10mm-50mm;4. Motor rotation direction: clockwise or counterclockwise;5.......
Send Inquiry
Product Description
Series motor
RY70 series
Main features:
1. The rated voltage / frequency is shown in the table below;
2. Shaft characteristics: diameter ∮5.∮6.∮6.35. ∮8 ∮9 shaft extension part thread, helical gear shaft or worm;
3. Stator stack thickness 10mm-50mm;
4. Motor rotation direction: clockwise or counterclockwise;
5. Temperature protection: thermostat or fuse;
6. Noise standard: 75dB-1000mm. Comply with GB / T10069.1-2006.
The main purpose:
Paper shredder, hair dryer, vacuum cleaner, soymilk machine, blender, juicer, etc.
RY70 series
Main features:
1. The rated voltage / frequency is shown in the table below;
2. Shaft characteristics: diameter ∮5.∮6.∮6.35. ∮8 ∮9 shaft extension part thread, helical gear shaft or worm;
3. Stator stack thickness 10mm-50mm;
4. Motor rotation direction: clockwise or counterclockwise;
5. Temperature protection: thermostat or fuse;
6. Noise standard: 75dB-1000mm. Comply with GB / T10069.1-2006.
The main purpose:
Paper shredder, hair dryer, vacuum cleaner, soymilk machine, blender, juicer, etc.
| model | Input power | No-load performance | Maximum efficiency point | Maximum output power point | Shaft extension length | |||||||||
| Voltage | frequency | Rotating speed | Electric current | effectiveness | Rotating speed | Torque | Electric current | power | Rotating speed | Torque | Electric current | |||
| VAC | HZ | RPM | A | % | RPM | mNm | a | W | RPM | mNm | A | mm | ||
| RY7015 | 120 | 60 | 19500 | 1.48 | 47.8 | 10059 | 89.2 | 2.21 | 169.3 | 5840 | 156.4 | 2.42 | 18 | |
| 220 | 50 | 20500 | 0.46 | 57 | 11800 | 83.4 | 0.92 | 166.7 | 6470 | 159.6 | 1.13 | |||
| RY7020 | 120 | 60 | 21500 | 1.42 | 53.2 | 10790 | 97.3 | 2.19 | 179.6 | 5960 | 183.6 | 2.52 | twenty two | |
| 220 | 50 | 19500 | 0.44 | 20.2 | 9883 | 106.2 | 1.07 | 126.83 | 6963 | 173.9 | 1.434 | |||
| RY7025 | 120 | 60 | 23500 | 1.20 | 54.2 | 10950 | 102.3 | 2.39 | 207.6 | 6390 | 228.6 | 2.83 | 30 | |
| 220 | 50 | 20000 | 0.52 | 57.2 | 9980 | 179 | 1.588 | 225.5 | 6653 | 324 | 2.229 | |||
| RY7030 | 120 | 60 | 22000 | 0.92 | 57 | 10395 | 141.6 | 2.63 | 204.7 | 6478 | 301.7 | 4.28 | 40 | |
| 220 | 50 | 22000 | 0.48 | 60.5 | 10587 | 172.4 | 1.53 | 236.3 | 7955 | 283.6 | 2.12 | |||
| RY7040 | 120 | 60 | 16500 | 0.74 | 56.8 | 7436 | 176.3 | 1.49 | 243.2 | 6240 | 294.6 | 2.02 | 50 | |
